Main Features
1. High precision and speed. Marking depth can be controlled easily. Continue working no need
maintenance.
2. U.A.S imported RF tube together with high speed galvanometer and path expander fans system.
stable path fast marking.
3. High-speed optical galvanometers are used for laser beam scanning.
4. Industry computer, strong anti-interference and adaptation stable working position for 24 working.
5. Red position system avoids material waste.
6. Multi-function software with friendly interface support win7/xp/2000 together with many languages
version. Supporting True Type font and single line font JSP, DMF, One-dimensional code and VIN code.
7. Supporting bmp, jpg, gif, tga, png, tif file together with ai, dxf, dst, plt. Work on 256 level grey image.
Image processing for grey conversion, black white conversion and dot.
8. Application: widely used in laser marking of hard, fragile, soft and cylindrical products or materials
in production lines.
Technical Parameters:
|
Model
|
DTML-10C(RF)
|
DTML-30C(RF)
|
DTML-50C(RF)
|
DTML-100C(RF)
|
|
Laser Head
|
|
Laser model
|
UL-10
|
UL-30
|
UL-50
|
UL-100
|
|
Laser power（W）
|
10
|
30
|
50
|
100
|
|
Beam quality M2
|
1.4
|
1.4
|
1.4
|
1.4
|
|
Beam diameter（mm）
|
4.0
|
4.0
|
4.0
|
4.0
|
|
Max. pulse frequency（kHz）
|
5
|
5
|
5
|
5
|
|
Cooling
|
Air
|
|
Marking Head
|
|
Scanner
|
High-speed optical galvanometer (USA)
|
|
Marking filed (mm)
|
50x50,70x70,105x105, 140x140, 175x175, 210x210 or 255x255
|
|
Max. scanning speed (m/sec)
|
8
|
|
Marking resolution (mm)
|
0.05
|
|
Dimension (mm)
|
210×138×120
|
|
Marking software
|
|
Various fonts, pictures (PLT, DXF, BMP), automated series numbers, barcodes, DataMatrix
|
Applications
--Non-metal materials and products: acrylic, ceramics, plastics, polycarbonate, organics, wood,
thermo-elastomer rubbers, paper, button.
--Electronic industry: capacitor, inductor, PCB, IC, connector, control panel, instrument.
--Others: button, cosmetics, food package, bottle, gift, advertisement & sign crafts, craft & gift
making.
