Main features
1. Single and double laser tube, working exchange freely according to customer is working inquiry.
Improve working efficiency.
2. Each laser head reaches to total working size. Free setting up distance between two laser head, works
frequently.
Technical Parameter
|
Model
|
DTCL-1610M
|
DTCL-1812M
|
|
Working Area(mm)
|
1600*1000
|
1800*1200
|
|
Laser Power
|
60w/80w/100w/130w/150w
|
|
Laser Type
|
CO2 Sealed Laser Tube , 10.6μm
|
|
Cooling Type
|
Water Cooling
|
|
Engraving Speed
|
0-60000mm/min
|
|
Cutting Speed
|
0-40000mm/min
|
|
Laser Output Control
|
0-100% set by software
|
|
Min. Engraving Size
|
Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm
|
|
Highest Scanning Precision
|
4000DPI
|
|
Locating Accuracy
|
≤+0.01mm
|
|
Controlling Software
|
DSP Control System
|
|
Graphic Format Supported
|
DST PLT BMP DXF DWG AI LAS,etc
|
|
Compatible Software
|
CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc.
|
|
Color Separation
|
Yes
|
|
Drive System
|
High-precision 3-phase Stepper Motor
|
|
Auxiliary Equipments
|
Exhaust Fan and Air Exhaust Pipe
|
|
Power Supply
|
AC110V/220V+10%,50HZ/60HZ
|
|
Working Environment
|
Temperature:0-45C,Humidity 5-95%(No Condensate Water)
|
Applications
--Applicable industry:
Mold industry(construction mold, aviation and navigation mold, wooden mold), advertising, decoration,
arts and crafts, electronics, electric appliances, etc.
--Applicable Materials:
Acrylic, wood planks(light planks,candlenut wood), bamboo ware, double color board, paper, leather,
shell, coconut shell, ox horn, resin animal grease, ABS board, lamp shade, etc.
