Integrated Electric Marking Machine

Product name：Integrated Electric Marking Machine

Item：DTME-1711I

Details：

Features

1. NO need computer: use Embedded Industrial Computer and high-definition LCD to replace
computer, easy operation;

2. No need air sources: unique magnetic technology to replace air sources, so no noise
when marking;

LCD control and operate, no need connect computer and air sources, no need adjust,
just plug in your power supply is ok, improved working efficiency a lot.

Technical Index

Model	DTME-1711I
Marking Range	170*110mm
Marking speed range	10~100 words/min (characters)
Marking depth range	0.05 ~ 0.5mm (according to materials )
Tag character content	0 ~ 9 figures, A ~ Z large, lowercase letters Graphics, characters (users can be random homemade)
Operating voltage	Control cabinet ~ 220V 50Hz ± 10%
Work Environment	Temperature: 5 ~ +35 C ° Humidity: ≤ 80% room
Safety	Insulation resistance:Normal atmospheric pressure≥5MΩ/500V
	Electric strength: ～50Hz、1500V 、1min
Leakage Current	≤0.75Ma

Application

--Applied industry: Mechanical working, Automobile Industry, Aeronautics,
Astronautics, and Petroleum equipment, etc.

--Applicable material: All kinds of metal, hard plastic, wood, etc.
