Main Features
1. 3 axes transmission with Taiwan ball screws ensures stable and smooth movement of the machine.
2. Solid gantry, well structure of lathe bed, stable lathe table.
3. Application of driver with high definition and subdivision ensures fast speed and high accuracy.
4. High-speed spindle with water cooling system works vigorously with low noise, guarantee long time mass processing.
5. Optimized mechanical and electrical design with well-selected brand parts minimizes breakdown rate.
6. Adopt advanced cnc system, configured with practical and easy-learned software, can conveniently check the moving path of tool, and adjust the processing depth of Z axis and the speed of motor.
7. Over-length in Y axis, can meet long-enough material engraving.
Technical Parameter
|
Description
|
Parameter
|
|
DTRA-09060A
|
|
Working Area (X*Y*Zmm)
|
900*6000*100mm
|
|
Max Engraving Speed
|
6000mm/min
|
|
Frame
|
Cast Steel
|
|
Spindle power(KW)
|
0.8kw,1.5kw(option: 2.2)
|
|
Max. Power Consumption(Without spindle)
|
1.2KW
|
|
Spindle Speed
|
6000-24000rpm
|
|
Resolution
|
0.005mm
|
|
Repeatability
|
0.01mm
|
|
Voltage
|
AC220V,50Hz/60Hz(option:AC110V,50Hz/60HZ)
|
|
Drive motor
|
Stepper(option:Servo motor)
|
|
Working Dictate
|
G Code
|
|
Operating system
|
Nc-studio(option:Dsp System,match 3 PC software)
|
|
Interface
|
USB
|
|
Flash memory
|
128M(U Disk)
|
|
Software Compatability
|
Type3,(option,Ucancam,Artcam Software)
|
|
Running Environemt
|
Temperature: 0℃～45℃
|
|
Relative humidity: 30%～75%
|
|
