Small Desktop Fiber Laser Marking Machine
Small Desktop Fiber Laser Marking Machine

Product name：Small Desktop Fiber Laser Marking Machine

Item：DTML-F(SD)

Details：

Main Features

1. Small desktop, can put on table, quite convenient to use;

2. More up&down space in Z aixs: the lens head can up&down freely, suitable for more thick
products demand.

3. The fool installation: just connect two wires, one with your computer(laptop), the other to
your power supply(220V/50Hz);

4. Can no need computer, reduce cost: after u receive the machine, just connect your laptop
to the machine with one wire will ok.

5. High speed 2-3 times over than traditional diode pumped marking machine.
6. Air-cooling, no after-sales services and maintenance.

7. Long lifetime: 100,000 hours=35years.

Main Advanced configurations
1. Raycus generator(best one in China market, guarantee 2 years, lifetime 100,000 hours); Or Germany IPG generator, best
in worldwide!
2. Germany technology lens head, max speed can reach 20000mm/s, highest precision;
3. Singapo field lens;
4. Beijing EzCad software, easy to use;
5. Taiwan power supply, best quality;

6. Air-cooling, no after-sales services and maintenance.
7. Long lifetime: 100,000 hours=35years.

Technical Parameters

Model

DTML-10F(SD)

DTML-20F(SD)

DTML-30F(SD)

DTML-50F(SD)

Other

Laser Power

10W

20W

30W

50W

......

Laser Wavelength

1064nm

Q-frequency

20KHz~30KHz

Divergence

0.3mard

Marking Range

110*110mm

Minimum Line Width

0.02mm

Minimum Character

0.15mm

Marking Depth

0 ~0.5mm

Engraving Line Speed

≤7000mm/s

Repeatability Accuracy

±0.001mm

Beam Quality

M2:1.2~1.8

Marking Format

Graphics, Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date, Batchnumber, Serialnumber, Frequency, etc.

Graphic Format Supported

bmp, jpg, gif, tga, png, tif, ai, dxf, dst, plt, etc.

Working Voltage

220V±10%/50Hz/4A

Unit Power

＜0.5kw

Use of the Environment

Clean and Dust Free or Dust less

Working Condition:Humidity

5%-75%，Free of Condensed Water

Laser Module Life

＞100000 hours

Applications

1. Mtal&Non-Metal materials and products:stainless steel, copper, aluminum alloy, acrylic, ceramics, plastics,
organics, thermo-elastomer rubbers, paper, scissors, bearing, gear, detonator;

2. Electronic industry: capacitor, inductor, oscillator, PCB, IC, connector, control panel, instrument.

3. Others: cosmetics, food package, bottle, gift, advertisement & signcrafts, craft & gift making.
