Main Features
1. Small and pretty, easy to move;2. Desktop, can put any places as u want ;
3. 100mm up&down worktable, can put thick materials;
4. 35w laser tube, can do delicate engraving, also can cut thin materials such as acrylic, wood, garments, leather, paper, etc
5. Easy foolish operation: just one button to start/shut down machine, then easiest software operation(for this u can refer to attached photo no.7);
6. High-speed slide guide rail with faster engraving & cutting speed
7. DSP control system: support offline work
8. Much more economical, cheaper a lot than common-in-China market small laser machines.
Technical Parameter
|
Model
|
DTCL-0503S(D2)
|
DTCL-0604S(D2)
|
|
Working/Engraving Area
|
535*350mm
|
600*450mm
|
|
Laser Power
|
35W
|
|
Laser Type
|
CO2 Sealed Laser Tube, 10.6μm
|
|
Cooling Type
|
Water Cooling
|
|
Engraving Speed
|
0-60000mm/min
|
|
Cutting Speed
|
0-40000mm/min
|
|
Laser Output Control
|
(0-100% Set by Software )
|
|
Min. Engraving Speed
|
Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm
|
|
Highest Scanning Precision
|
4000DPI
|
|
Locating Precision
|
≤+0.01mm
|
|
Controlling Software
|
DSP Control System
|
|
Graphic Format Supported
|
DST PLT BMP DXF DWG AI LAS,etc
|
|
Compatible Software
|
TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,etc
|
|
Color Separation
|
Yes
|
|
Drive System
|
High-precision 3-phase Stepper Motor
|
|
Auxiliary Equipments
|
Exhaust Fan and Air Exhaust Pipe
|
|
power Supply
|
AC110V/220V+10%,50HZ/60HZ
|
|
Working Environment
|
Temperature:0-45℃,Humidity 5-95%(No Condensate Water)
|
|
Optional Spare Parts
|
Honeycomb Worktable, Rotary Device,Auto-focus Device
|
Applications
Applicable industry:
Mould industry (construction mould, aviation and navigation mould, wooden mould), advertising,
decoration, arts and crafts, electronics, electric appliances, etc.
Applicable Materials:
materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board,
paper, leather, shell, coconut shell, ox horn, resin animal grease, ABS board, lamp shade, etc.
